MF-FEM450 Auto elastic band inserting mahcine
INTRODUCTION
The machien is used for inserting the elastic band to hard cover. It automatically delivers the cover, cuts the elastic band, inserts and sticks the elastic band into the cover, greatly enhancing the working efficiency and product quality.
Details
1.
2.
3.
4.
MAIN SPECIFICATIONS:
| Power supply | 360V 50Hz |
| Speed | 1500pcs/hour |
| Max cover size | 310 x 450mm |
| Min cover size | 140 x 190mm |
| Elastic band margin | 15-20mm |
| Elastic band size | 6-12m |
| Cases thickness | 1.5-4mm |
| Power | 6kW |
| Machine dimensions | 2650 x 1600 x 1650mm |
| Weight | 1300kg |
