MF-450A Auto end papering machine
INTRODUCTION
The MF-450A automatic end paper gluing machine is an ideal postpress binding equipment for various printing and binding factories. Itcan be used for pasting single or multiple pages of paperback, aswell as for pasting the ring lining of hardcover books and notebooksbefore the lock line of the book block, greatly meeting customers'labor saving needs.
Details
With auto feeding part
Without auto feeding part
MAIN SPECIFICATIONS:
| Power supply | 380V 3P 50Hz |
| Mainframe power | 4.6kW |
| Machine speed | 3000PCS/Hour |
| Block thickness | 30mm |
| End paper thickness | 70gsm - 2mm |
| Book block size Max | 450 x 310mm |
| Book block size Min | 155 x 100mm |
| Machine dimensions | 4800 x 1800 x 1700mm |
| Machine dimensions | 4800 x 1800 x 1700mm |
| Machine weight | 1200kg |
