MF-HBM420 Book block head band machine
INTRODUCTION
Book Head and Tail Banding Machine MF-HBM420 is designed for past-ing the head and tail band onto the round and square book blocks. It isthe perfect solution for medium and small book binding companies.This model apply the double adhesive tape,automatically deliveringdown the head band and tape, automatically pasting tape to the headband, automatically cutting the head band. The machine does not re-quire cleaning at the end of the production.
MAIN FEATURES
1.
2.
3.
MAIN SPECIFICATIONS:
| Power supply | 220V 1 Phase 50Hz |
| Mainframe power | 1.5kW |
| Air compressor | 6Bar |
| Machine speed | 1-15pcs/minute |
| Book block thickness | 10-60mm |
| Book block size max | 350 x 420mm |
| Book block size min | 100 x 100mm |
| Machine dimensinons | 700 x 850 x 1550mm |
| Machine weight | 150kg |
